Product Details
Place of Origin: Zhejiang China
Certification: CE/SGS/ISO9001
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiate
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Model NO.: |
J614F |
Trademark: |
Xuteng |
Origin: |
China |
HS Code: |
8481801090 |
Supply Ability: |
10000PCS/Week |
Size: |
Dn15-80 |
Transport Package: |
Carton |
Specification: |
CE/SGS/ISO9001 |
Customization: |
Available | Customized Request |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Model NO.: |
J614F |
Trademark: |
Xuteng |
Origin: |
China |
HS Code: |
8481801090 |
Supply Ability: |
10000PCS/Week |
Size: |
Dn15-80 |
Transport Package: |
Carton |
Specification: |
CE/SGS/ISO9001 |
Customization: |
Available | Customized Request |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Technology Parameter Model Pipe Connection Kv Value Max. Pressure Resistance Min. Pressure Resistance Performe Sizemm direction of flow polyamide Aluminum alloy KLJZF-15 G1/2 4.2 0~1.6 0.39 50 A OR B KLJZF-20 G3/4 8 0~1.1 0.39 50 KLJZF-25 G1 19 0~1.1 0.42 63 KLJZF-32 G11/4 27.5 0~1.5 0.5 63 100 KLJZF-40 G11/2 42 0~1.25 0.44 63 100 KLJZF-50 G2 55 0~1.0 0.4 125 Installation & Maintenance: 1 Clean the pipes carefully from any residue, dribble or welding residue, to avoid any damage to the seal. 2 To be installed as required, preferably with actuator in upright position 3 Connect the pipes according to the reference points (fl ow direction) found on the valve body. Only disassemble the actuator if required by customer. 4 Before taking the valve apart, depressurize the media supply and pilot air supply piping system. |
