Product Details
Place of Origin: Zhejiang China
Certification: CE/SGS/ISO9001
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiate
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Model NO.: |
Z41H |
Material: |
Cast Steel |
Connection Form: |
Flange |
Pressure: |
Ordinary Temperature |
Actuator: |
Electric,Pneumatic,Manual |
Seal Surface: |
Wedge Gate Valve |
Thread Position Of Valve Rod: |
Outside Gate Valve |
Usage: |
Regulation, Safety, Emptying, Drain, Temperature Control, Flow Control |
Standard: |
JIS10K-20K,ANSI Class150-900,Pn1.0-32.0MPa |
Application: |
Industrial Usage, Water Industrial Usage |
Size: |
DN15-400 |
Bw End Dimension: |
ASME B16.25 |
Socket-Weld Dimension: |
ASME B16.11 |
Face To Face And End To End: |
ASME B16.10 |
Transport Package: |
Plywood |
Specification: |
CE/SGS/ISO9001 |
Trademark: |
XuTeng |
Origin: |
China |
HS Code: |
8481804090 |
Supply Ability: |
10000PCS/Year |
Package Size: |
30.00cm * 30.00cm * 30.00cm |
Package Gross Weight: |
5.000kg |
Media: |
Oil, Water ,Gas,Acid |
Temperature: |
Ordinary Temperature |
Type: |
Straight-through |
Customization: |
Available | Customized Request |
Shipping Cost : |
About Shipping Cost And Estimated Delivery Time. |
: |
Initial Payment Full Payment |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Model NO.: |
Z41H |
Material: |
Cast Steel |
Connection Form: |
Flange |
Pressure: |
Ordinary Temperature |
Actuator: |
Electric,Pneumatic,Manual |
Seal Surface: |
Wedge Gate Valve |
Thread Position Of Valve Rod: |
Outside Gate Valve |
Usage: |
Regulation, Safety, Emptying, Drain, Temperature Control, Flow Control |
Standard: |
JIS10K-20K,ANSI Class150-900,Pn1.0-32.0MPa |
Application: |
Industrial Usage, Water Industrial Usage |
Size: |
DN15-400 |
Bw End Dimension: |
ASME B16.25 |
Socket-Weld Dimension: |
ASME B16.11 |
Face To Face And End To End: |
ASME B16.10 |
Transport Package: |
Plywood |
Specification: |
CE/SGS/ISO9001 |
Trademark: |
XuTeng |
Origin: |
China |
HS Code: |
8481804090 |
Supply Ability: |
10000PCS/Year |
Package Size: |
30.00cm * 30.00cm * 30.00cm |
Package Gross Weight: |
5.000kg |
Media: |
Oil, Water ,Gas,Acid |
Temperature: |
Ordinary Temperature |
Type: |
Straight-through |
Customization: |
Available | Customized Request |
Shipping Cost : |
About Shipping Cost And Estimated Delivery Time. |
: |
Initial Payment Full Payment |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| SIZE: 1"- 12" CLASS: 150LB-2500LB Design and Manufacture: Cast steel gate vlave to API 600(ISO 10434) or API 6D, cast stainless steel gate valve to API 603 or API 600; Forged steel gate valve to API 602 Inspection and Test: ASME B16.5(for NPS≤ 24); ASME B16.47 series B, API 605 or ASME B16.47 series A, MSS SP-44 (for NPS bigger than 24) End flange dimension: API 598, API 600 or API 6D BW end dimension: ASME B16.25 Socket-weld dimension: ASME B16.11 Face to face and end to end: ASME B16.10 Pressure-temperature ratings: ASME B16.34 |
